Wear Resistant Steel Plates

  1. Home
  2. Products
  3. Wear Resistant Steel Plates

Wear plates are made for rock-processing machinery, crushers and power shovels containing about 1.2 percent carbon and 12 percent manganese. Its wear resistant traits have high work-hardening capabilities. The Wear Resistant Steel - XAR 400, is comprised of elevated wear resistance and good welding ability. With the special chemical composition, XAR 400 is combined with a heat treatment by quenching or tempering. Owing to its alloying and rigidity, this steel ensures reliable amalgamation. The steel possesses chemical composition with moderately low carbon equivalents. The key quality for wear resistant steels is their hardness. We offer wear plates as per its hardness measured on the Brinnell Hardness Test. It additionally helps to diminish the support expenses connected with wear and breakdown of a plant. The steel is extinguished, which gives wear safety to enhance hardness and it might also be tempered. For the most part it gives great cool twisting properties and great weldability. Weldability is not, by and large lessened as the hardness increases. Its attributes are excellent wear resistance, high impact resistance and smooth finish.

Wear-Resistant-Steel-Plates
Wear-Resistant-Steel-Plates
Wear-Resistant-Steel-Plates
  • Width - 600mm to 3000mm
  • Surface Treatment - Coated and Galvanized
  • Grade - XAR 400
  • Technique - Cold Rolled
  • Type - Steel Plate
  • Development of apparatus, skips, bulldozers, excavators, buckets, and conveyors
  • Manufacturing of structures and gears
  • Truck couches
  • Connections to diggers and earthmovers
  • Earthmoving buckets
  • Dragline buckets
  • Mining business
  • Demolition tools
  • Ground engaging tools
  • Chutes
  • ROCK STAR 400 | DILLIDUR 400 | HARDOX 400 | QUARD 400
  • ABREX 400 | ARNA PRO 500 | DILLIDUR 500 | HARDOX 500
  • QUARD 500 | ABREX 500

SPECIFICATIONS

Specifications Chemical Mechanical Mpa, min
C
Max		 Mn
Max		 Si
Max		 S
Max		 P
Max		 Cr
Max		 Mo
Max		 Ni
Max		 B
Max		 CE
Max		 HARDNESS
BHN		 Tensile Yield % EL
HARDOX 400 0.12 1.25 0.47 0.002 0.011 0.035 0.6 0.04 0.004 0.40 370/430 1200 1000 10%
HARDOX 500 0.30 1.6 0.7 0.01 0.02 0.035 0.6 1.5 0.005 0.43 470/530 1450 1250 12%
DILLIDUR 400 0.2 1.8 0.7 0.01 0.025 0.035 0.5 0.8 0.005 0.49 370/430 1200 800 12%
DILLIDUR 500 0.30 1.6 0.7 0.01 0.0025 0.035 0.5 1 0.005 0.57 470/530 1600 1100 9%
QUARD 400 0.17 1.6 0.6 0.01 0.025 0.035 0.3 0.1 0.005 0.45 370/430 1300 1160 10%
QUARD 500 0.3 1.6 0.8 0.01 0.025 0.035 0.5 1 0.005 0.61 470/530 1700 1500 12%
ROCK STAR 400 0.18 1.6 0.7 0.01 0.025 0.035 0.25 0.25 0.004 0.48 370/430 1250 1000 12%
ARMA PRO 0.32 1.2 0.7 0.01 0.025 0.035 0.7 1.8 0.005 0.7 480/540 1450 1250 8%
ABREX 400 0.21 2 0.7 0.01 0.025 0.035 0.6 1 0.005 0.7 360/440 1290 1000 10%
ABREX 500 0.35 2 0.7 0.01 0.015 0.035 0.6 1 0.005 0.7 450/550 1705 1500 12%
