A cold rolled steel sheet is produced by pickling a hot coil and rolling it uniformly at an appropriated temperature to a thinner thickness. It has excellent surface configuration and superb mechanical properties for use in automobile and electronic appliance production.

Cold-Rolled-Coils
Cold-Rolled-Coils
Cold-Rolled-Coils
  • Thickness - 0.5mm to 3.15mm
  • Width - 800mm to 1600mm
  • Material - Mild Carbon Steel
  • Length - Can be cut to sheets according to the requirement
  • Max. Weight - 20 MT per coil
  • White goods and furniture
  • Flooring systems
  • Tube making
  • Containers and drums
  • Shelving
  • Automotive parts
  • Precision tubes
  • Packaging industry
  • A 1008: DS type A & B, DDS, EDDS, EDDS+

SPECIFICATIONS

Cold Rolled 1008/1010 Steel Physical Properties
ASTM A1008/1010
Temper Designation Alloy
Dead Soft DS Type - B 1008
Commercial Quality DS Type - B 1008/1010
1/4 Hard   1008/1010
1/2 Hard   1008/1010
Full Hard   1008/1010



Cold Rolled 1008/1010 Chemical Composition
ASTM A1008/1010
Designation C Mn P S Al Si Cu Ni Cr Mo V Cb Ti N B
DS Type A 0.10 0.60 0.030 0.035 - - 0.20 0.20 0.15 0.06 0.008 0.008 0.025 - -
DS Type B 0.02-0.015 0.60 0.030 0.035 - - 0.20 0.20 0.15 0.06 0.008 0.008 0.025 - -
DS Type C 0.08 0.60 0.10 0.035 - - 0.20 0.20 0.15 0.06 0.008 0.008 0.025 - -
DS Type A 0.08 0.50 0.020 0.030 0.01 min - 0.20 0.20 0.15 0.06 0.008 0.008 0.025 - -
DS Type B 0.02-0.08 0.50 0.020 0.030 0.02 min - 0.20 0.20 0.15 0.06 0.008 0.008 0.025 - -
DDS 0.06 0.50 0.020 0.025 0.01 min - 0.20 0.20 0.15 0.06 0.008 0.008 0.025 - -
EDDS 0.02 0.40 0.020 0.020 0.01 min - 0.10 0.10 0.15 0.03 0.10 0.10 0.025 - -
Note: All values referenced are max unless otherwise specified
